Use & Functionality

Permanent measurement of charge density and dosing of polymeric flocculants with the PolyLyzer®

Integrate the PolyLyzer® wherever auxiliary materials are used for solid/liquid separation.

The integration of the PolyLyzer® is very simple. We set up the device and actively support you in connecting it to your existing system. The analyzer is placed near the centrate discharge. The only need is the program change of the existing PCL, which we are happy to accompany as well.

Application Areas

  • Sewage sludge dewatering
  • Sewage sludge thickening
  • Drinking water treatmen
  • Flotation
  • Sedimentation
  • Filtration

Control with reference variable charge quantity and charge density, proportional to quantity

PolyLyzer KAM Funktionsweise

Supported dewatering units

  • Screw press
  • Decanter centrifuges
  • Belt presses

Requirements for integration

  • Power connection 220 - 240 volt
  • Water connection with GK coupling
  • Sample line
  • Drain
  • Connection to SPS

Technical information

Parameter charge density
Measuring range -100/+100 µeq/l     -500/+500 µeq/l     -1000/+1000 µeq/l     -2000/+2000 µeq/l
Dimensions 450 x 600 x 800 mm (TxBxH)
Weight 65 kg
Electrical connection 115 – 230 V 50 – 60 Hz
Outputs (0)4 – 20 mA alarm relay; operation relay; Profibus optionally
Inputs Remote control
Connections remote control; sampling line; water supply; optional purge air

Datenblatt als PDF

Laden Sie sich hier das Produktdatenblatt herunter
